CONECTOR TE CON ROSCA DE CONEXIÓN CENTRAL MS 607 |
|||
CÓDIGO |
Ø TUBO |
ROSCA DE CONEXIÓN - A1 |
ROSCA DE |
607-001 |
1/8” |
1/8” BSPT |
UNF 5/16” x 24 |
607-002 |
3/16” |
1/8” BSPT |
UNF 3/8” x 24 |
607-003 |
¼” |
1/8” BSPT |
UNS 7/16” x 24 |
607-004 |
¼” |
¼” BSPT |
UNS 7/16” x 24 |
607-005 |
5/16” |
1/8”BSPT |
UNS ½” x 24 |
607-006 |
5/16” |
1/4” BSPT |
UNS ½” x 24 |
607-007 |
3/8” |
1/8”BSPT |
UNEF 9/16” x 24 |
607-008 |
3/8” |
¼” BSPT |
UNEF 9/16” x 24 |
607-009 |
½” |
¼” BSPT |
UN 11/16” x 20 |
607-010 |
½” |
3/8” BSPT |
UN 11/16” x 20 |
607-011 |
5/8” |
1/2” BSPT |
13/16” x 18 |
|
|
|
|
607-012 |
6mm |
1/8” BSPT |
M12x1,5 |
607-013 |
6mm |
¼”BSPT |
M12x1,5 |
607-014 |
8mm |
¼”BSPT |
M14x1,5 |
607-015 |
10mm |
¼”BSPT |
M16x1,5 |
607-016 |
12mm |
¼”BSPT |
M16x1,5 |
607-017 |
12mm |
3/8”BSPT |
M18x1,5 |
