UNIÓN RECTA - MS 505 |
||
CÓDIGO |
Ø TUBO |
ROSCA DE |
505-001 |
1/8” |
UNF 5/16” x 24 |
505-002 |
3/16” |
UNF 3/8” x 24 |
505-003 |
1/4” |
UNF 7/16” x 20 |
505-004 |
5/16” |
UNF 1/2” x 20 |
505-005 |
3/8” |
UNF 5/8” x 18 |
505-006 |
7/16” |
UN 11/16” x 16 |
505-007 |
1/2” |
UNF 3/4” x 16 |
505-008 |
5/8” |
UNF 7/8” x 14 |
505-009 |
3/4” |
1 1/16” x 14 |
